E16 Double Acting – Bore Size (inch): 0.627

Category: Double-Acting
Basic specifications
plus toggleminus toggle

Double Rod End includes the stroke options listed here: 0.5–1.0–1.5–2.0–3.0–4.0–5.0–6.0-7.0–8.0–9.0–10.0–11.0–12.0 Use the dropdown box below to choose the appropriate stroke for your need.

Track locations for optional sensor-ready Airpel configuration.

Optional Sensor Track Details

Configure your part
Mounting option

Pair this product with:

IM0060063

Position Sensors

View product
airpot ffr product image1

Filter Regulators

View product
Airpot offers four product families in our line of customizable pneumatic actuator.
GET FREE SAMPLE
Get a free sample

CONTACT

sales@airpot.com
203-846-2021
Airpot Corporation 35 Lois Street, Norwalk, CT 06851, US

FOLLOW US

HOURS OF OPERATION

Monday-Friday:
8:00 a.m. – 4:30 p.m. ET
TRC ISO
Design and Development by Noble House Media Group
© 2026 Airpot. All rights reserved
Airpot®, Airpel®, Airpel Plus®, Airpel-AB®, and Gramforce® are registered trademarks of Airpot Corp.

We are using cookies to give you the best experience on our website.

You can find out more about which cookies we are using or switch them off in .

    This 3D file is not available.

    However if you submit this form, our engineers will create the 3D file for you.

    Please answer the math question below to prove you are a human!
    This site is protected by reCAPTCHA and Google
    Privacy Policy and Terms of Service apply.

    MODEL
    M32
    M33
    Bore (mm) 32.5 32.5
    Maximum Pressure (MPa) 0.7 0.7
    Suitable for Vacuum Actuation? No Yes
    Maximum Stock Stroke (mm) 175 300
    Custom Strokes Available? No Yes
    Works with Position Sensors (switches)? Yes (bracket required) Yes
    Port Size M5 G 1/8
    The M33 weight is less than the M32.
    The M33 cycle life is higher than the M32.
